Manufacturer:Panametrics
Model Number:704-673-20
Type:Ultrasonic Flow Meter
Flow Range:0.3 to 30 m/s
Accuracy:±0.5% of reading ±0.025 m/s
Repeatability:±0.025 m/s
Operating Temperature:-20°C to +80°C
Pressure Rating:Up to 400 bar
Output:4-20 mA, HART, RS-485 Modbus
Communication Protocol:Modbus RTU/ASCII, HART
Power Supply:10-36 VDC
Weight:2.5 kg
Dimensions:100mm x 100mm x 150mm (LxWxH)
The PANAMETRICS 704-673-20 ultrasonic flow meter is designed for precise and reliable measurement of fluid flow in industrial environments. Its non-invasive design ensures no moving parts or obstructions within the pipe, reducing maintenance and downtime.
This model offers high accuracy with a range of 0.1 to 30 meters per second, making it suitable for a wide variety of applications including water treatment, chemical processing, and oil & gas industries. The accuracy of +/- 0.5% of reading ensures consistent and dependable measurements.
The device is built to withstand harsh industrial conditions with an operating pressure up to 100 bar and temperature range from -20°C to +150°C. This makes it ideal for use in demanding environments where precision and reliability are critical.
Equipped with RS-485 Modbus RTU communication protocol, the 704-673-20 can easily integrate with existing SCADA systems and other industrial automation networks. A 24 VDC power supply ensures stable operation, and the 4-20 mA output allows for seamless integration with control systems.
Installation and maintenance are simplified with its compact and robust design. The non-invasive sensor requires minimal setup time and can be installed without interrupting the process flow, making it a cost-effective solution for industrial flow measurement.
